Item |
XHS-QD-D130 |
XHS-QD-D260 |
XHS-QD-D590 |
XHS-QD-D610 |
XHS-QD-D8120 |
|
Total power KW |
4.95Kw |
5.2Kw |
8.3Kw |
11.3Kw |
16.8Kw |
|
Input voltage |
three phase 380V |
three phase 380V |
three phase 380V |
three phase 380V |
three phase 380V |
|
Wire feeding servo motor |
2Kw |
2.0Kw |
2.3Kw |
3.8Kw |
5.5kw |
|
Cutting servo motor |
0.75Kw |
1.0Kw |
2.0Kw |
2.0Kw |
3.8Kw |
|
Straightening motor |
2.2Kw |
2.2Kw |
4Kw |
5.5Kw |
7.5kw |
|
straightening mold |
Alloy |
Alloy |
Alloy |
Cast iron/ Alloy |
Cast iron/ Alloy |
|
Applicable wire diameter range |
1-3mm |
2-6 mm |
5-9 mm |
6-10 mm |
5-12 mm |
|
Maximum cutting speed |
120 items/min |
120 items/min |
120 items/min |
90 items/min |
90 items/min |
|
Stable straightening speed |
25-35m/min |
25-35m/min |
25-35m/min |
20-30m/min |
20-30m/min |
|
Length accuracy error |
±0.5mm |
±0.5mm |
±0.5mm |
±0.5mm |
±0.5mm |
|
cutting length |
Above 10mm |
Above 10mm |
Above 10mm |
Above 20mm |
Above 20mm |
|
outline dimension |
1400*500*1450 |
1400*500*1450 |
1700*850*1450 |
1800*850*1450 |
1900*850*1450 |
|
（Length × Width × Height） |
|||||
|
Machine weight（Kg） |
430 |
430 |
480 |
530 |
630 |
